Particular Matter Sensor PM2.5

Particulate Matter Sensor (SAPS PM2.5)

PM2.5 refers to particulate matter with diameters of up to 2.5 microns, which are among the most dangerous air pollutants. Due to their small size, PM2.5 particles can travel deep into the human lung and cause a variety of health issues. Sensirion's automotive grade PM2.5 sensor solution monitors the level of those pollutants in the air inside the cabin and communicates them to the HVAC controller through LIN. Based on the information from the PM2.5 sensor, the HVAC controller can take actions to ensure low dust concentration and high air quality to increase passengers’ comfort.

Read More

Air Quality Sensor

Air Quality Sensor (SAAQ SERIES)

The sensors of the SAAQ product family are designed to accurately measure traffic-related odors, pollutants and gases and, optionally, the relative humidity and temperature of the air that enters the HVAC system. As a unique feature compared to current AQS-sensors, the SAAQ-series is resilient against Siloxanes thereby ensuring true and reliable long-term stability. In particular, the sensor provides accurate measurement signals throughout its lifetime. Using these values, the SAAQ sensor automatically calculates the air quality level and, optionally, the dew point temperature. This information is then used by the HVAC controller to control the fresh-air/recirculation flap. The standard LIN interface allows for easy system integration.

Read more

Ionizer

Ionizer (SAIO SERIES)

Sensirion’s ionizer generates 36,800 negative ions. When installed close to the air outlet of the passenger cabin, it creates a fresh air effect inside the passenger cabin similar to being near a waterfall or in the mountains, thereby increasing passengers’ comfort. The ionizer provides different electrical interface options (LIN or analog). It features a small and compact form factor for easy integration in the HVAC air flow channel.

Read More

Cabin Air Temperature Sensor

CABIN AIR TEMPERATURE SENSOR (SACT SERIES)

The cabin air temperature sensor is used for accurate control of the temperature inside the cabin. Thanks to its built-in fan, the sensor has a fast response time, which enables the HVAC controller to reach the desired set point quickly and efficiently. The Sensirion SACT series features a low noise fan solution and a small form factor for easy installation. The product family offers various options for housing, mounting and electrical interface (LIN or analog).

Read More

Anti-Fogging/Auto-Defrost Sensor

Anti-Fogging/Auto-Defrost Sensor (SAAF SERIES)

The relative humidity sensors in the SAAF product family are designed to accurately measure the relative humidity (RH) and temperature (T) inside the windshield, thereby enabling the climate control system to actively prevent fogging. The product family offers various options for mounting, electrical interfaces and connectors. The sensor signals are fully calibrated, linearized and temperature-compensated, allowing the SAAF product family to ensure high accuracy across a wide range of humidity and temperature conditions, including temperatures well below 0°C.

Read more

Dew Point

DEW POINT SENSOR (SADP SERIES)

Sensirion Automotive Solutions’ dew point sensor contributes to both the energy efficiency of the HVAC and comfortable humidity levels in the cabin. Mounted inside the HVAC system, the SADP sensor measures the temperature, relative humidity and dew point temperature of the air. These signals can be used by the HVAC controller to cool down the evaporator only as much as really needed to ensure a comfortable climate inside the cabin, thereby saving energy. Unnecessarily low temperatures and resulting dehumidification can thus be avoided. The SADP sensors feature easy mounting solutions with bayonet or Delphi clip as well as a standard LIN interface.

Read More
